Oxygen Free Copper Upcast Machine 4000 Tons Furnance Oven Continuous Casting Machine
Product Details:
| Place of Origin: | Dongguan,china |
| Brand Name: | Hongli |
| Certification: | CE,ISO |
| Model Number: | HL4000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | 80,00$-150,000$ |
| Packaging Details: | wooden packing |
| Delivery Time: | 60-120 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100 set per year |
|
Detail Information |
|||
| Name: | Oxygen Free Copper Upcast Machine | Size: | 4000 T |
|---|---|---|---|
| Copper Size: | 8-17mm Square Mm | Production Speed: | 180-220mm/min |
| Motor Brand: | Siemens | Inverter Brand: | Yaskawa |
| Main Motor: | 120kw+120kw | Power Consumption: | 325kwh/ton |
| Oven Size: | 300-500Kg | ||
| High Light: | Oxygen Free Copper Upcast Machine,Copper Upcast Machine 4000 Tons,Furnance Oven Continuous Casting Machine |
||
Product Description
4000 Tons Furnance Oven Continuous Casting Machine For Oxygen-Free Copper From Scrap Copper To 8mm
About us:
Our factory has been manufacturing extrusion lines for over 20 years ,we also produce copper buncher, cable twisting machine, cable tapping machine, copper drawing machine.Until now we have exported some production lines to Pakistan, iraq,Tunisia, Algerial, Egypt, India, Afghanistan,Nigeria, Sudan, we are still working on other country,
Main brands for our machine
| Copper Scrap Solution Comparison | ||||
| Process | Purity | Scrap Quantity | Product/Purity | Main Equipment |
| CCR | >95.2% | 10KT-50KT/annually | Rod/99.9% | Furnace, Casting/rolling, fume treatment |
| Adding to upcast after refinery | >96% | 1-3KT/annually | Rod/99.9% | Refining furnace, Up casting line |
| Adding to upcast without refinery | >99.5% | 5-20KT/annually | Rod/99.95% | Up casting line |
| Direct Electrolysis | >96% | <2 KT/a nnually | Cathode/99.95% | Electrolysis system, water purification |
| Anode Electrolysis | 90-92% | 5KT-150KT/annually | Cathode/99.97% | Refinery furnace, fume treatment,anode caster, electrolysis system, water purification |
Summery
The up casting line is one of our strength products, it is the best way of making oxygen free copper rods. With its advantages of flexible capacity and product size, compact process, economic power installation and consumption. The rods of our up casting line are widely used as raw material for continuous extrusion and enameling.
Upward continuous casting oxygen-free copper rod production line (called the plant as follow), it is used for producing the big length shining/bright oxygen-free copper rod, the big length shining oxygen-free copper tube and the big length shining oxygen-free copper flat strip, etc.
Craftwork flow
Cathode copper/Scrap copper → melting furnace → transition chamber → holding furnace → casting machine (crystal molding) → casting rod → take-up device → on sale or further producing
Put the cathode copper into the melting furnace of QL1 compounded furnace straightly. It will be melted into liquid by a frequency inductor. Then the liquid of copper smoothly pass through the transition chamber and will flood into the holding furnace automatically , and then it will be deoxidized by the charcoal covered. The liquid of copper will become a casting rod quickly by the crystallizer of the casting machine in the holding furnace. Then it will be hauled by the double-withdrawal roller of the casting machine. When the casting rod is hauled off, it will be led to take-up device.
